Digital Microscope - Standard Working Distance / 10x-220x / Caps / 5MP / EDOF / EDR | Dino Lite AM7915MZT

Digital microscope with high resolution 5 megapixel sensor, EDOF (Extended Depth of Field) and EDR (Extended Dynamic Range) for impressive quality digital imaging.

This high quality handheld microscope also features a rugged metal housing and adjustable polarization. Comes with interchangeable caps for protection from dust and liquids, alternative lighting and magnification, plus a precision calibration target. Ideal for non-destructive analysis, highly precise cleaning, characterisation tests and condition recording.

  • Additional caps allow further flexibility in use, i.e. sealed caps for dusty environments or protection from liquids
  • 5 megapixel sensor providing 2592x1944 pixel resolution, capture video (30 fps) and still images
  • EDOF (Extended Depth of Field) see example in images, combines images at different focus levels for overall clarity on uneven surfaces (Windows only)
  • EDR (Extended Dynamic Range) combination of images at different levels of exposure for clarity (Windows only)
  • AMR (automatic magnification reading) shows clearly the level of magnification through the software (Windows only)
  • 10x - 220x continuous adjustable magnification
  • Polarizer filter allows you to reduce or eliminate glare on reflective surfaces and also can provide the ability to see through the surface of fully or partially transparent materials, such as textiles, paint, glass, and plastic
  • Complete with software (Windows and Mac compatible - read more here) and all necessary cables, simple USB 2.0 setup
  • Annotate and measure images to 0.001mm
  • Flexible control of the 8 LED lighting
  • Robust metal body with simple to operate dials for focus and polarisation

microscope specification

More details in 'Specification' tab below.

Available Accessories: Stands & stand accessories (see 'Recommended' items below), Image capture footswitch for hands-free operation (see below), WiFi streamer for wireless video streaming to mobile or desktop devices.

Read More
Microscope Dino-Lite Dino Lite AM7915MZT
P873-7915MZT 873-7915MZT
Pack Size: Each Price: £1,025.00 ex VAT In Stock
Accessories to fit
Microscope Stand RK-06A Dino Lite
P873-RK-06A 873-RK-06A
Pack Size: Each Price: £200.00 ex VAT Low Stock
Microscope Stand RK-10A Dino Lite
P873-RK-10A 873-RK-10A
Pack Size: Each Price: £270.00 ex VAT In-stock 14 days
Microscope Stand MS52BA2
P873-MS52BA2 873-MS52BA2
Pack Size: Each Price: £320.00 ex VAT In Stock 48hr
Microscope Stand RK-02
P873-RK-02 873-RK-02
Pack Size: Each Price: £130.00 ex VAT Low Stock
Microscope Wifi Streamer Dino Lite
P873-WF-10 873-WF-10
Pack Size: Each Price: £260.00 ex VAT In Stock 48hr
Microscope Foot Switch Dino Lite
P873-SW-F1 873-SW-F1
Pack Size: Each Price: £50.00 ex VAT In Stock 48hr

For more detail on the features of our digital microscopes, read our blog post here

MAGNIFICATION RATE WORKING DISTANCE *   FIELD OF VIEW(X)   FIELD OF VIEW(Y)   DEPTH OF FIELD
Listed values may differ slightly
* Without front cap     Unit = mm
10 136.0 37.8 28.3 -
20 60.2 19.5 14.6 2.5
30 33.5 13.0 9.7 1.8
40 20.9 9.8 7.3 1.5
50 13.9 7.8 5.8 -
60 9.7 6.5 4.8 -
70 7.1 5.6 4.2 1.0
80 5.5 4.9 3.6 -
90 4.5 4.3 3.2 -
100 4.1 3.9 2.9 -
110 4.0 3.6 2.7 -
120 4.1 3.3 2.4 -
130 4.5 3.0 2.2 -
140 5.0 2.8 2.1 -
150 5.6 2.6 1.9 -
160 6.3 2.4 1.8 -
170 7.1 2.3 1.7 -
180 8.0 2.2 1.6 -
190 8.9 2.1 1.5 -
200 9.9 2.0 1.5 -
210 10.9 1.9 1.4 -
220 11.9 1.8 1.3 0.1

    LIGHTING

  • Light/ LED type: White
  • Number of LEDs: 8
  • LED on/off switchable: Yes
  • Infrared filter: IR cut-filter >650 nm
  • Diffuser available: Yes (N3C-D included)
  • Emission filter: No
  • Polarizer: Yes, linear
  • OPTICS

  • Magnification: 10-220x
  • Macro zoom: No
  • Working distance: Standard
  • Lens type: Glass with anti-reflection coating
  • SENSOR

  • Sensor type: CMOS
  • Resolution: 5 Megapixel (2592x1944)
  • Maximum frame rate: 30 fps
  • COMPATIBILITY

  • Interface: USB 2.0
  • Operating system: Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up
  • Included software: DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
  • Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
  • Supported video formats (Windows): WMV, FLV, SWF
  • Supported image formats (MacOS): -
  • Supported video formats (MacOS): -
  • Imaging standards: DirectShow, UVC
  • HOUSING

  • Housing material: Metal housing
  • Magnification lock: Yes
  • Dimensions: 10.5cm (L) x 3.2cm (D)
  • Weight: 137g
  • Cable length: 1.8m
  • FEATURES

  • Special feature: Aut. Magn. reading, Ext. Dynamic Range (EDR), Ext. Depth of Field (EDOF), Flexible LED Control (FLC)
  • Measurement: Yes
  • Calibration: Yes
  • Microtouch sensor: Yes
  • ESD safe: Yes
  • INFORMATION

  • Package contents:
    Microscope, Carry pouch, Software CD, User manual, Quick guide, Calibration target, Front cover box, Exchangeable caps
  • Regulatory approval: CE, FCC, ROHS
