Digital Microscope - Long Working Distance / 10x-90x / ABS | Dino Lite AM4113ZTL

Digital Microscope with long working distance, handheld design for portability, featuring 10x-90x magnification power. Ideal for non-destructive analysis, highly precise cleaning, characterisation tests and condition recording from a distance of 40mm-150mm. The long working distance is the right choice when working on high glare materials such as metals and plastics, and to allow space for working on an object while viewing through the microscope.

  • 1.3 megapixel sensor providing 1280x1024 pixel resolution, capture video (30fps) and still images
  • Long working distance 40mm-150mm from object
  • 10x-90x magnification
  • Polarizer filter allows you to reduce or eliminate glare on reflective surfaces and also can provide the ability to see through the surface of fully or partially transparent materials, such as textiles, paint, glass, and plastic
  • Complete with software (Windows and Mac compatible - read more here) and all necessary cables, simple USB 2.0 setup
  • Annotate and measure images to 0.001mm
  • ABS plastic body with simple to operate dials for focus and polarisation
  • 8 (white) LED illumination which can be switched on or off

More details in 'Specification' tab below.

microscope specification

Available Accessories: Stands & stand accessories (see 'Recommended' items below), Image capture footswitch for hands-free operation (see below), WiFi streamer for wireless video streaming to mobile or desktop devices.

Read More
Microscope Long Working Distance Dino-Lite AM4113ZTL
P873-4113ZTL 873-4113ZTL
Pack Size: Each Price: £420.00 ex VAT In-stock 14 days
Accessories to fit
Microscope Stand RK-06A Dino Lite
P873-RK-06A 873-RK-06A
Pack Size: Each Price: £200.00 ex VAT Low Stock
Microscope Stand RK-10A Dino Lite
P873-RK-10A 873-RK-10A
Pack Size: Each Price: £270.00 ex VAT In-stock 14 days
Microscope Stand MS52BA2
P873-MS52BA2 873-MS52BA2
Pack Size: Each Price: £320.00 ex VAT In Stock 48hr
Microscope Stand RK-02
P873-RK-02 873-RK-02
Pack Size: Each Price: £130.00 ex VAT Low Stock
Microscope Wifi Streamer Dino Lite
P873-WF-10 873-WF-10
Pack Size: Each Price: £260.00 ex VAT In Stock 48hr
Microscope Foot Switch Dino Lite
P873-SW-F1 873-SW-F1
Pack Size: Each Price: £50.00 ex VAT In Stock 48hr
MAGNIFICATION RATE WORKING DISTANCE FIELD OF VIEW(X) FIELD OF VIEW(Y) DEPTH OF FIELD
Listed values may differ slightly       Unit = mm
20 160.5 19.8 14.9 6
30 110.4 13.2 9.9 3.4
40 86.7 9.9 7.4 2.2
50 73.6 7.9 5.9 1.65
60 65.7 6.6 5.0 -
70 60.8 5.7 4.2 -
80 57.8 5.0 3.7 -
90 56.1 4.4 3.3 0.8

    LIGHTING

  • Light/ LED type: White
  • Number of LEDs: 8
  • LED on/off switchable: Yes
  • Infrared filter: IR cut-filter >650 nm
  • Diffuser available: MSAA111A2 (optional accessory)
  • Emission filter: No
  • Polarizer: Yes, linear
  • OPTICS

  • Magnification: 10-90x
  • Macro zoom: No
  • Working distance: Long
  • Lens type: Glass with anti-reflection coating
  • SENSOR

  • Sensor type: CMOS
  • Resolution: 1.3 Megapixel (1280x1024)
  • Maximum frame rate: 30 fps
  • COMPATIBILITY

  • Interface: USB 2.0
  • Operating system: Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up
  • Included software: DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
  • Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
  • Supported video formats (Windows): WMV, FLV, SWF
  • Supported image formats (MacOS): JPEG, PNG
  • Supported video formats (MacOS): MOV
  • Imaging standards: DirectShow, UVC
  • HOUSING

  • Housing material: Composite/ plastic housing
  • Magnification lock: Yes
  • Dimensions: 10.5cm (L) x 3.2cm (D)
  • Weight: 105g
  • Cable length: 1.8m
  • FEATURES

  • Special feature: No
  • Measurement: Yes
  • Calibration: Yes
  • Microtouch sensor: Yes
  • ESD safe: No
  • INFORMATION

  • Package contents: Microscope, Carry pouch, Software CD, Calibration target, ZT-Z-CC1 Cap closure, User manual
  • Regulatory approval: CE, FCC, ROHS
