Digital Microscope - UV+IR LED / Standard Working Distance / 20-200x / ABS | AD4113T-I2V

Digital Microscope with standard working distance, handheld design for portability, featuring UV + Infrared led lighting and up to 200x magnification power. Ideal for non-destructive analysis, characterisation tests and condition recording.

Features both IR (~940nm) and UV (~395nm) LED lighting in a single device.

  • UV (395nm) and Infrared (~940nm) LED lighting
  • Additional caps allow further flexibility in use, i.e. sealed caps for dusty environments or protection from liquids
  • High resolution 5megapixel sensor providing 2592x1944 pixel resolution, capture video (30fps) and still images
  • 20x - 200x magnification
  • Complete with software (Windows and Mac compatible - read more here) and all necessary cables, simple USB 2.0 setup
  • Annotate and measure images to 0.001mm
  • ABS plastic housing

microscope specification

More details in 'Specification' tab below.

Read More
Microscope Special Lighting Dino-Lite AM4113T-I2V
P873-4113T-L2V 873-4113T-L2V
Pack Size: Each Price: £425.00 ex VAT In Stock
Accessories to fit
Microscope Stand RK-06A Dino Lite
P873-RK-06A 873-RK-06A
Pack Size: Each Price: £200.00 ex VAT Low Stock
Microscope Stand RK-10A Dino Lite
P873-RK-10A 873-RK-10A
Pack Size: Each Price: £270.00 ex VAT In-stock 14 days
Microscope Stand RK-02
P873-RK-02 873-RK-02
Pack Size: Each Price: £130.00 ex VAT Low Stock
Microscope Stand MS52BA2
P873-MS52BA2 873-MS52BA2
Pack Size: Each Price: £320.00 ex VAT In Stock 48hr
Microscope Wifi Streamer Dino Lite
P873-WF-10 873-WF-10
Pack Size: Each Price: £260.00 ex VAT In Stock 48hr
Microscope Foot Switch Dino Lite
P873-SW-F1 873-SW-F1
Pack Size: Each Price: £50.00 ex VAT In Stock 48hr

    LIGHTING

  • Light/ LED type: ~395 nm UV + ~940 nm Infrared
  • Number of LEDs: 4+4
  • LED on/off switchable: Yes
  • Infrared filter: No
  • Diffuser available: No
  • Emission filter: No
  • Polarizer: No
  • OPTICS

  • Magnification: 20-200x
  • Macro zoom: No
  • Working distance: Standard
  • Lens type: Glass with anti-reflection coating
  • SENSOR

  • Sensor type: CMOS
  • Resolution: 1.3 Megapixel (1280x1024)
  • Maximum frame rate: 30 fps
  • COMPATIBILITY

  • Interface: USB 2.0
  • Operating system: Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up
  • Included software: DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
  • Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
  • Supported video formats (Windows): WMV, FLV, SWF
  • Supported image formats (MacOS): JPEG, PNG
  • Supported video formats (MacOS): MOV
  • Imaging standards: DirectShow, UVC
  • HOUSING

  • Housing material: Composite/ plastic housing
  • Magnification lock: Yes
  • Dimensions: 10.5cm (L) x 3.2cm (D)
  • Weight: 105g
  • Cable length: 1.8m
  • FEATURES

  • Special feature: No
  • Measurement: Yes
  • Calibration: Yes
  • Microtouch sensor: Yes
  • ESD safe: No
  • INFORMATION

  • Package contents: Microscope, Carry pouch, Software CD, Open and closed cap, Calibration target, User manual
MAGNIFICATION RATE WORKING DISTANCE FIELD OF VIEW(X) FIELD OF VIEW(Y) DEPTH OF FIELD
Listed values may differ slightly       Unit = mm
20 51.7 25.1 20.1 4
30 24.1 16.8 13.4 2
40 11.0 12.6 10.1 1.6
50 3.8 10.1 8.0 1.17
60 -0.6 8.4 6.7 -
200 -0.4 2.5 2.0 0.28
210 0.6 2.4 1.9 -
220 1.7 2.3 1.8 -
230 2.8 2.2 1.7 -
