Digital Microscope - UV+White LED / 20x-220x / Standard Working Distance / AM4115T-FUW

Digital Microscope with standard working distance, handheld design for portability, featuring UV + White led lighting and up to 220x magnification power. Ideal for non-destructive analysis, characterisation tests and condition recording.

With LED lighting, switchable between white and UV light. This model has a filter to filter out the returning UV light so that an image with natural colours can be obtained.

  • UV (375nm) and white LED lighting
  • Additional caps allow further flexibility in use, i.e. sealed caps for dusty environments or protection from liquids
  • 1.3 megapixel sensor providing 1280x1024 pixel resolution, capture video (30fps) and still images
  • 20x - 220x magnification
  • Complete with software (Windows and Mac compatible - read more here) and all necessary cables, simple USB 2.0 setup
  • Annotate and measure images to 0.001mm
  • ABS plastic housing with simple to operate dial for focus

microscope specification

More details in 'Specification' tab below.

Available Accessories: Stands & stand accessories (see 'Recommended' items below), Image capture footswitch for hands-free operation (see below), WiFi streamer for wireless video streaming to mobile or desktop devices.

Read More
Microscope Special Lighting Dino-Lite AM4115T-FUW
P873-4115T-FUW 873-4115T-FUW
Pack Size: Each Price: £479.00 ex VAT In Stock 48hr
Accessories to fit
Microscope Stand MS35B
P873-MS35B 873-MS35B
Pack Size: Each Price: £95.00 ex VAT Due in Stock
Microscope Stand RK-02
P873-RK-02 873-RK-02
Pack Size: Each Price: £110.00 ex VAT In Stock 48hr
Microscope Stand RK-06A
P873-RK-06A 873-RK-06A
Pack Size: Each Price: £159.00 ex VAT Due in Stock
Microscope Stand RK-10A
P873-RK-10A 873-RK-10A
Pack Size: Each Price: £230.00 ex VAT Due in Stock
Microscope Stand MS52BA2
P873-MS52BA2 873-MS52BA2
Pack Size: Each Price: £320.00 ex VAT In Stock 48hr
Microscope Wifi Streamer
P873-WF-10 873-WF-10
Pack Size: Each Price: £221.00 ex VAT In Stock 48hr
Microscope Foot Switch
P873-SW-F1 873-SW-F1
Pack Size: Each Price: £45.00 ex VAT In Stock 48hr
  • LIGHTING
  • Light/ LED type: ~375 nm UV + white
  • Number of LEDs: 4+4
  • LED on/off switchable: Yes
  • Infrared filter: IR cut-filter >650 nm
  • Diffuser available: MSAA111A1 (optional accessory)
  • Emission filter: Yes, Emission barrier filter 375 nm
  • Polarizer: No

    OPTICS

  • Magnification: 20-220x
  • Macro zoom: No
  • Working distance: Standard
  • Lens type: Glass with anti-reflection coating
  • SENSOR

  • Sensor type: CMOS
  • Resolution: 1.3 Megapixel (1280x1024)
  • Maximum frame rate: 30 fps

    COMPATIBILITY

  • Interface: USB 2.0
  • Operating system: Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up
  • Included software: DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
  • Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
  • Supported video formats (Windows): WMV, FLV, SWF
  • Supported image formats (MacOS): JPEG, PNG
  • Supported video formats (MacOS): MOV
  • Imaging standards: DirectShow, UVC

    HOUSING

  • Housing material: Composite/ plastic housing
  • Magnification lock: Yes
  • Dimensions: 10.5cm (L) x 3.2cm (D)
  • Weight: 105g
  • Cable length: 1.8m

    FEATURES

  • Special feature: No
  • Measurement: Yes
  • Calibration: Yes
  • Microtouch sensor: Yes
  • ESD safe: No

    INFORMATION

  • Package contents: Microscope, Carry pouch, Software CD, Calibration target, User manual
MAGNIFICATION RATE WORKING DISTANCE 1 WORKING DISTANCE 2* FIELD OF VIEW(X) FIELD OF VIEW(Y) DEPTH OF FIELD
Listed values may differ slightly
  * Without front cap     Unit = mm
20 52.7 60.2 19.5 15.6 2.5
30 26.0 33.5 13.0 10.4 1.8
40 13.4 20.9 9.8 7.8 1.5
50 6.4 13.9 7.8 6.3 -
60 2.2 9.7 6.5 5.2 -
70 - 7.1 5.6 4.5 1.0
80 - 5.5 4.9 3.9 -
90 - 4.5 4.3 3.5 -
100 - 4.1 3.9 3.1 -
110 - 4.0 3.6 2.8 -
120 - 4.1 3.3 2.6 -
130 - 4.5 3.0 2.4 -
140 - 5.0 2.8 2.2 -
150 - 5.6 2.6 2.1 -
160 - 6.3 2.4 2.0 -
170 - 7.1 2.3 1.8 -
180 - 8.0 2.2 1.7 -
190 - 8.9 2.1 1.6 -
200 - 9.9 2.0 1.6 -
210 - 10.9 1.9 1.5 -
220 - 11.9 1.8 1.4 0.1
