Digital Microscope - UV / Standard Working Distance / 10x-70x & 200x / ABS | Dino Lite AM4113T-FV2W

Digital Microscope with standard working distance, handheld design for portability, featuring UV led light and up to 200x magnification power. Ideal for non-destructive analysis, characterisation tests and condition recording.

With LED lighting, switchable between white and UV (375nm) light. This model has a filter to filter out the returning UV light so that an image with natural colours can be obtained.

  • UV (375nm) and white LED lighting
  • 1.3 megapixel sensor providing 1280x1024 pixel resolution, capture video (30fps) and still images
  • 10x-70x, 200x magnification (10x - 70x continuous, 200x fixed)
  • Complete with software (Windows and Mac compatible) and all necessary cables, simple USB 2.0 setup
  • Annotate and measure images to 0.001mm
  • ABS plastic body with simple to operate dials for focus and polarisation

microscope specification

More details in 'Specification' tab below.

Read More
Microscope Special Lighting Dino-Lite AM4113T-FV2W
P873-4113T-FV2W 873-4113T-FV2W
Pack Size: Each Price: £310.00 ex VAT In Stock 48hr
Accessories to fit
Microscope Stand RK-02
P873-RK-02 873-RK-02
Pack Size: Each Price: £110.00 ex VAT Low Stock
Microscope Stand RK-06A Dino Lite
P873-RK-06A 873-RK-06A
Pack Size: Each Price: £159.00 ex VAT In Stock 48hr
Microscope Stand RK-10A Dino Lite
P873-RK-10A 873-RK-10A
Pack Size: Each Price: £230.00 ex VAT In Stock 48hr
Microscope Stand MS35B
P873-MS35B 873-MS35B
Pack Size: Each Price: £95.00 ex VAT In Stock 48hr
Microscope Wifi Streamer Dino Lite
P873-WF-10 873-WF-10
Pack Size: Each Price: £221.00 ex VAT In Stock 48hr
Microscope Foot Switch Dino Lite
P873-SW-F1 873-SW-F1
Pack Size: Each Price: £50.00 ex VAT In Stock 48hr

MAGNIFICATION RATE WORKING DISTANCE FIELD OF VIEW(X) FIELD OF VIEW(Y) DEPTH OF FIELD
Listed values may differ slightly       Unit = mm
20 48.7 19.8 14.9 3.6
30 21.7 13.2 9.9 1.9
40 9.0 9.9 7.4 -
50 1.9 7.9 5.9 0.88
60 -2.3 6.6 5.0 -
220 -0.1 1.8 1.4 0.20
230 1.0 1.7 1.3 -
240 2.1 1.7 1.2 -

    <h4>LIGHTING</h4>


  • Light/ LED type: ~375 nm UV + white
  • Number of LEDs: 4+4
  • LED on/off switchable: Yes
  • Infrared filter: IR cut-filter >650 nm
  • Diffuser available: MSAA111A1 (optional accessory)
  • Emission filter: Yes, Emission barrier filter 375 nm
  • Polarizer: No

    OPTICS

  • Magnification: 10-70x, 200x
  • Macro zoom: No
  • Working distance: Standard
  • Lens type: Glass with anti-reflection coating

    SENSOR

  • Sensor type: CMOS
  • Resolution: 1.3 Megapixel (1280x1024)
  • Maximum frame rate: 30 fps

    COMPATIBILITY

  • Interface: USB 2.0
  • Operating system: Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up
  • Included software: DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
  • Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
  • Supported video formats (Windows): WMV, FLV, SWF
  • Supported image formats (MacOS): JPEG, PNG
  • Supported video formats (MacOS): MOV
  • Imaging standards: DirectShow, UVC

    HOUSING

  • Housing material: Composite/ plastic housing
  • Magnification lock: Yes
  • Dimensions: 10.5cm (L) x 3.2cm (D)
  • Weight: 105g
  • Cable length: 1.8m

    FEATURES

  • Special feature: No
  • Measurement: Yes
  • Calibration: Yes
  • Microtouch sensor: Yes
  • ESD safe: No

    INFORMATION

  • Package contents: Microscope, Carry pouch, Software CD, Calibration target, User manual
  • Warranty information: 2 years European warranty
  • Regulatory approval: CE, FCC, ROHS
